配件:分频外置

         带全套原装联接线

         喇叭线

        原装脚钉

        调音后垫大理石板

以下是Audio Physic Medea数据:

Description: Patented full-range drivers with 80 Hz - 35 kHz frequency

 response Two-way speaker design Built in 300 watt powered bass

 management (See Rhea subwoofer) Tuned cabinets Speaker/

 cainet matched to +-0.5 dB pairs Completely phase and time coherent response

-----------

采用Manger 最高级全音域喇叭W05/1,2.2.16

一对箱共采用六支Manger W05/1,2.2.16 全音域喇叭和一对低音

以下是Manger W05/1,2.2.16 全音域喇叭的数据:

resonance frequency fs = 88 Hz
impedance R = 8 Ohm
sound pressure level SPL = 91 dB (2.83V; 1m)
DC resistance Re = 7.2 Ohm
force factor BL = 4.31 N/A
voice coil inductance L = 7.44 mH
effective piston radiating area Sd = 220 cm2
equivalent volume of compliance Vas = 15 l
total Q factor Qts = 0.88 (Qms=2.94. Qes=1.25)
maximum peak linear excursion vibration xlin = +/- 3.5 mm
mounting diameter d = 192.5 mm
overall diameter d = 211 mm
mounting depth (not countersunk) t = 22 mm
----------

著名单元应用在音箱情况表:

驱动单元 音箱品牌和型号
* 表示经过音箱设计厂家修改 * 表示型号太旧或者该型号存在周期较短
Manger W05/1,2.2.16 Audio Physic Medea ($49,995+/pr)
B&R WaveLaunch Cavendish ($7,977/pr, active; $6,699/pr, passive)
Manger Zerobox 107/3 ($6,009+/pr)
Manger Zerobox 107/1 ($3,392+/pr)
Manger Zerobox 108 ($6,212+/pr)
Manger Zerobox 109 ($2,460+/pr)

----------------
