V90-DAC - Specifications
Performance
Jitter: <12 picoseconds peak to peak
THD(+ noise): <0.004% 20Hz to 20 kHz
Frequency Response: +0, –0.1dB, 20Hz to 20 kHz
Crosstalk: -104dB, 20Hz to 20 kHz
Signal / Noise ratio: -117dB, 20Hz to 20 kHz
Inputs
1x RCA coaxial connector SPDIF 32-192 kbps (16-24 bit stereo PCM)
2x TOSLINK optical connector 32-96 kbps (16-24 bit stereo PCM)
1x USB type 'B' connector - Asynchronous data stream at up to 24-bit/96kHz (Determined by source file/computer settings)
Outputs
1x line level RCA (phono)
General
Dimensions - WxHxD (mm): 170 x 47 x 102
Weight (unpacked / packed): 600g / 1.1 kg
Supplied Accessories
1x 12v 500mA DC power supply
