Cygnus(胡桃木色)
Coming directly from Lynx project, the Constellation Cygnus exploits a floor standing design to increase low frequency radiation by adding a dedicated subwoofer at the bottom of the cabinet. Slim and gently back slanted it perfectly stands in any living room, offering to the listener both a detailed reproduction and a powerful low frequency range.
The valuable solid wood of the cabinet sides together with the HDF supporting frame make the whole structure to be virtually motionless, allowing a recognizable sturdy front stage during any demanding low frequency / high level musical passages.
A jewel of stunning power.
Low Frequency Load
Vented 2π sr NRS
Configuration
3way floor standing
Drivers
1 Tweeter 38mm soft dome T38 WaveGuide
1 Midrange 130 mm Paper Compound
1 Woofer 130 mm Paper Compound
Sensitivity
87 dB SPL normalized to 1m with 2.83Vrms pink noise within IEC 268-13 compliant listening room
Low Frequency Cut Off
50 Hz @ -3dB referred to C4WETS
Xover Frequencies
170/1,500 Hz
Alignment
LKR 4th order
Rated Impedance
4Ω
Suggested Ampilfier
Rated for 120W/4Ω max Average Power
Size
955x200x270mm (HxWxD)
Weight
17kg
Cabinet Finishing
Solid walnut or solid cherry and HDF
Speakers Orientation
Tilted inward facing the listener
Optional Spikes
Black anodized iron – Thread M-6 with locking disk & floor saver
Notes
All quantities in SI Units
Average Power computed as V2rms/R
Speakers not shielded
Specs subject to change without notice
