Specification
ItemValueSystem Format:Frequency Response:Sensitivity (1W@1M):Nominal Impedance:Maximum SPL (dBA):Power Handling (RMS):Recommended Amplifier Requirements (RMS):Bass Alignment:Crossover Frequency:Drive Unit Complement:Cabinet Dimensions:
(Excluding Grille & Terminals) (H x W x D)Product External Dimensions:
(Including Terminals) (H x W x D)Product External Dimensions:
(Including Grille & Terminals) (H x W x D)Individual Weight:
2 Way
40Hz - 35kHz
88dB
8 Ohms
112.6 (pair)
120W
40-120W
Bass reflex - rear ported
HiVe®II port System
2.0kHz
1 x 8" RST® Bass/Mid driver
1 x 1" (25mm) C-CAM® gold dome tweeter
375 x 230 x 300 mm
(14 3/4 x 9 1/16 x 11 13/16 inch)
375 x 230 x 323 mm
(14 3/4 x 9 1/16 x 12 11/16 inch)
375 x 230 x 335 mm
(14 3/4 x 9 1/16 x 13 3/16 inch)
9.7 Kg (21 lb 6 oz)
