S/3参数规格:
TYPE:Front-firing active driver, down-firing passive
ACTIVE DRIVER SIZE & MATERIAL:10 in., 250mm long-throw, Continuous CastAlloy™ cone structure, cast chassis
PASSIVE RADIATOR SIZE & MATERIAL:12 in., 300mm Carbon/Carbon flat cone structure, steel chassis
LOW FREQUENCY EXTENTION:-6dB at 21 Hz
INPUT CONNECTORS:CONNECTORS High Level Neutrik Speakon, Low Level stereo RCA, LFE RCA, SMA for wireless antenna
OUTPUT CONNECTORS:N/A
POWER OUTPUT:400 watts (RMS)
AMPLIFIER TYPE:NextGen2 Class D
WIRELESS CAPABILITY:Longbow (Optional), Zero Compression, Individual discrete D/A and A/D Encoders
Protection System
FULLY ELECTRONIC SET SAFE:Yes
D.C. FAULT:Yes
OUTPUT SHORT:Yes
MAINS INPUT VOLTAGE:220-240 volts, 110-120 volts for certain markets
FUSES:5 Amp 220 volts operation, 9 Amp 120 volts operation
Dimensions
W X H X D:16 x 16.7 x 18.25 in. (406 x 424 x 463.5 mm)
NET WEIGHT:61.4 lbs. (27.85 kg)
FINISH:Piano Black Lacquer, White Lacquer, 8 coats
