S/5参数规格:
TYPE:Front-firing active driver, down-firing passive
ACTIVE DRIVER SIZE & MATERIAL:
12 in., 300mm long-throw, Continuous CastAlloy™ cone structure, cast chassis
PASSIVE RADIATOR SIZE & MATERIAL:
12 in., 300mm Carbon/Carbon flat cone structure, steel chassis
LOW FREQUENCY EXTENTION:-6dB at 20 Hz
INPUT CONNECTORS:High Level Neutrik Speakon, Low Level stereo RCA, LFE RCA, SMA for wireless antenna
OUTPUT CONNECTORS:N/A
POWER OUTPUT:550 watts (RMS)
AMPLIFIER TYPE:NextGen2 Class D
WIRELESS CAPABILITY:Longbow (Optional), Zero Compression, Individual discrete D/A and A/D Encoders
Protection System
FULLY ELECTRONIC SET SAFE:Yes
D.C. FAULT:Yes
OUTPUT SHORT:Yes
MAINS INPUT VOLTAGE:220-240 volts, 110-120 volts for certain markets
FUSES:5 Amp 220 volts operation, 9 Amp 120 volts operation
Dimensions
W X H X D:17.5 x 18 x 20 in. (444.5 x 455.5 x 507 mm)
NET WEIGHT:69.7 lbs. (31.6 kg)
FINISH:Piano Black Lacquer, White Lacquer, 8 coats
