马田 Coltrane 3
TECHNICAL SPECIFICATIONS
Frequency range / 20-60000 Hz +-2dB
Power rating / 350 W
Sensitivity / 88 dB / 1 m / 2.83V
Impedance / 6 ohm (3.7 Ohm min)
Type / 3-way bass reflex
Drive units /
2x10² aluminium sandwich , 1x7² ceramic, 1x1² diamond
Crossover frequency / first order: 320 & 3800 Hz
Terminals / WBT, bi-wiring
Internal wiring / Jorma Design
Cabinet / 25 mm:s carbon fibre laminate cabinet, 68 mm laminated wood/aluminium front
Stands / Brushed stainless steel with Black Diamond Racing pucks and cones
Dimensions (WxHxD) /
39.5 cm x122 cm x 64 cm (15.5² x 48.0² x 25.2²)
Net weight / 95 Kg (209 lbs)
