8200A
技术参数:
一般说明:Integrated Amplifier
输出功率:2 x 60W RMS into 8 ohms
输入功率:CD, TUNER, AUX, VIDEO, TAPE 1, TAPE 2
输入阻抗:20kΩ
灵敏度:782mV
增益:Pre-Amp: 9dB
频率响应:20Hz - 20kHz ±0.5dB/ 1Hz - 65kHz -3dB
讯噪比:Line Input: Better than 80dB
Power Amp: better than 80dB
总谐波失真:Less than 0.07%
声道分隔:Better than 60dB
前级输出:Maximum Output >7.3V RMS
连接插头:100Ω
耳机输出:330Ω(suitable for headphone 8Ω - 2kΩ impedance)
录音讯号输出:VIDEO OUT, TAPE1 OUT, TAPE2 OUT
功率消耗:440VA
尺寸(W x H x D)mm:445×74×335
重量:7.4kg
