IS-1000 LINE
Power output: 125W@8Ω per channel
Upgraded DAC: BurrBrown PCM1792A
INTEGRATED AMPLIFIER Class AB Mosfet (125W @ 8Ω)
PHONO STAGE MM & MC developed from the multi-awarded PH-10
DAC DELUXE model: BurrBrown PCM1792A
LINE model: BurrBrown PCM1796
THD (Total Harmonic Distortion) 0,005% @5W
0,1% @ 0,1 to 50W (20Hz-20 kHz)
DAMPING FACTOR
>100
SIGNAL TO NOISE RATIO >100dB Line and Digital Inputs
>80 dB Phono (MM)
BOOSTER 3 adjustable levels (by-passable/off)
DSD DSD64
NETWORK CONNECTIVITY LAN & Wi-Fi
HIGH-QUALITY STREAMING Roon Ready, MQA, Airplay, vTuner, Tidal, Qobuz, Deezer, Spotify Connect
SUPPORTED MEDIA SERVERS Minim Server
Bubble UPnP
All certified UPnP media servers
SUPPORTED AUDIO FORMATS AIFF (aif, aiff, aifc)
WAV (wav) packed/unpacked FLAC
WmA Windows media Audio 9
WAX Windows media audio metafiles
ASX Advanced Stream Redirector (asx)
MPEG-4 (aac, m4a , Apple lossless)
MP3
DSD64 [.dsf] files converted to high-resolution PCM over UPnP protocol
INPUTS AND OUTPUTS
DIGITAL INPUTS 1x RCA Coax PCM up to 24bit/192kHz
3x Optical Tos-Link PCM up to 24bit/192kHz
1x USB-A port DSD64 and PCM up to 24bit/192kHz, formatted in FAT32/NTFS (32Gb max for pen drives)
ANALOGUE INPUTS 1x XLR balanced
1x RCA Line/Phono MM/MC
1x RCA Line/AV-In
ANALOGUE OUTPUTS 1x RCA fixed (0dB, 1.4Vrms)
1x RCA variable (+9,5dB, 4Vrms max)
OUTPUT IMPEDANCE 50Ω
DIMENSIONS AND WEIGHT
DIMENSIONS 430mm W | 135mm H | 375mm D
WEIGHT Kg. 18 – net
Kg. 23 – boxed
