| FREQUENCY RESPONSE |
45Hz-20kHz +/-3dB |
| POWER HANDLING |
100W continuous / 400W peak |
| recommended amplifier power |
150W |
| SENSITIVITY |
93dB @ 2.83V / 1m |
| NOMINAL IMPEDANCE |
8 ohms compatible |
| HIGH FREQ CROSSOVER |
2500Hz |
| HIGH FREQUENCY DRIVERS |
Dual 1" (2.5cm) Titanium diaphragm compression drivers mated to WDST™ Tractrix® Horn Array |
| LOW FREQUENCY DRIVERS |
Dual 5.25" (13.3cm) high-output, Cerametallic™ cone woofers |
| ENCLOSURE MATERIAL |
MDF & Aluminum motorboard / ABS shell |
| ENCLOSURE TYPE |
Bass-reflex via front-firing port |
| DIMENSIONS |
15.25" (38.7cm) dia |
| MOUNTING DEPTH |
9.5" (24.1cm) |
| CUTOUT DIMENSIONS |
13.25" (33.7cm) dia |
| INSTALLATION KIT |
IK-502-C (sold seperately) |
| WEIGHT |
11lbs (5kg) |
| FINISHES |
White paintable frame and grille |
| BUILT FROM |
2008 |
