设计

2-driver, 2-way sealed enclosures with integrated baffle and chassis. Low-diffraction grilles maximize imaging and ensure smooth dispersion. Cast-aluminum cabinet construction.

分频器

3rd-order electro-acoustic at 2.4 kHz

频率响应   On-Axis

±2 dB 120 Hz – 20 kHz

频率响应   30° 离轴

±2 dB 120 Hz – 18 kHz

高音单元

25-mm (1 in) S-PAL™ satin-anodized pure-aluminum dome

中音单元

102-mm (4 in) S-PAL™ satin-anodized pure-aluminum cone

低音下潜

76 Hz (DIN)

灵敏度   房间/消声室

89 dB / 86 dB

阻抗

Compatible with 8 ohms

颜色

Black Gloss

重量

6.5 lbs. (2.96 kg)

尺寸   高x宽x深
Including stand

7.75" × 4.5" × 5.75"
(19.7cm × 11.5cm × 14.6cm)
