设计

L/R inputs, 3-driver, 2 x 2-way in-wall / in-ceiling, GRIP™ chassis / mounting bracket

分频器

2nd-order electro-acoustic at 2.5 kHz

频率响应   On-Axis

±2 dB from 60 Hz - 22 kHz

频率响应   30° 离轴

±2 dB from 60 Hz - 16 kHz

高音单元

Two 25-mm (1 in) S-PAL™ domes, die-cast heatsink

Mid/Bass Frequency Driver

Dual voice-coil, 210-mm (8 in) mineral-filled polypropylene cone

低音下潜

45 Hz (DIN)

灵敏度   房间/消声室

91 dB / 87 dB

阻抗

Compatible with 4 ohms Mono; 8 ohms / channel Stereo Input

合适的放大器功率范围 Range

15 - 110 watts Mono; 15 - 55 watts / channel Stereo Input

最大输入功率

50 watts

颜色

White, paintable

重量

4.6 lbs. (2.1 kg)

Overall 尺寸

8.5" (21.4cm) Height
8.5" (21.4cm) Width

Cut-Out 尺寸

7.5" (19.1cm) Height
7.5" (19.1cm) Width

最小安装深度
Depth required is the distance
between 1/2" drywall, or similar material.

3.25" (8.3cm)

最少内部容积

0.70 cu ft (20 L)
