百里登 AMS-100RX
AMS-100RX Specifications
设计
2-driver, 2-way in-ceiling / in-wall, stainless steel grilles, Xtreme Moisture Application™ version, GRIP™ chassis / mounting bracket
分频器
2nd-order electro-acoustic at 2.5 kHz
频率响应 On-Axis
±2 dB from 75 Hz - 22 kHz
频率响应 30° 离轴
±2 dB from 75 Hz - 18 kHz
高音单元
25-mm (1 in) S-PAL™ dome, die-cast heatsink
Mid/Bass Frequency Driver
165-mm (6-1/2 in) mineral-filled polypropylene cone
低音下潜
55 Hz (DIN)
灵敏度 房间/消声室
89 dB / 85 dB
阻抗
Compatible with 8 ohms
合适的放大器功率范围 Range
15 - 100 watts
最大输入功率
80 watts
颜色
White, paintable
重量
3.3 lbs. (1.5 kg)
Overall 尺寸
7.6875" (19.5cm) Diameter
Cut-Out 尺寸
6.75" (17.2cm) Diameter
最小安装深度
Depth required is the distance
between 1/2" drywall, or similar material.
3" (7.6cm)
最少内部容积
0.42 cu ft (12 L)
